Edelbrock E-Street Cylinder Heads 5023

Name: Edelbrock E-Street Cylinder Heads 5023
Brand: CKY Performance
Price: 1408.95 USD
Availability: InStock

Edelbrock E-Street Cylinder Heads 5023

$1,408.95 USD

Sale Sold out

Product variants

Quantity

Brand:

Edelbrock

Manufacturer's Part Number:

5023

Part Type:

Cylinder Heads

Product Line:

Edelbrock E-Street Cylinder Heads

Summit Racing Part Number:

EDL-5023

UPC:

085347050239

Combustion Chamber Volume (cc):

60

Intake Runner Volume (cc):

170cc

Exhaust Runner Volume (cc):

60cc

Cylinder Head Style:

Assembled

Cylinder Head Material:

Aluminum

Intake Port Shape:

Rectangular

Intake Valve Diameter (in.):

1.900 in.

CNC-Machined Combustion Chamber:

No

CNC-Machined Intake Runner:

No

CNC-Machined Exhaust Runner:

No

Combustion Chamber Style:

Heart

Intake Port Location:

Standard

Exhaust Port Shape:

Square

Exhaust Port Location:

Standard

Intake Valves Included:

Yes

Exhaust Valves Included:

Yes

Exhaust Valve Diameter (in.):

1.600 in.

Valve Springs Included:

Yes

Maximum Valve Lift (in.):

0.550 in.

Camshaft Style:

Hydraulic flat tappet

Outside Diameter of Outer Spring (in.):

1.460 in.

Damper Spring Included:

Yes

Number of Springs Per Valve:

Single

Retainers Included:

Yes

Retainer Material:

Steel

Locks Included:

Yes

Lock Style:

7 degree

Valve Stem Seals Included:

Yes

Valve Stem Seal Style:

Umbrella

Rocker Arm Studs Included:

Yes

Rocker Arm Nut Thread Size:

3/8 in.-24

Rocker Arms Included:

No

Rocker Arm Nuts Included:

No

Guideplates Included:

Yes

Guideplate Pushrod Size:

5/16 in.

Valve Cover Mounting Style:

Perimeter bolt

Accessory Bolt Holes Drilled:

Yes

Valve Guides Included:

Yes

Valve Guide Material:

Manganese bronze

Valve Seats Machined:

Yes

Valve Seat Machine Style:

3-angle

Valve Seat Material:

Powdered metal

Cylinder Head Color:

Natural

Steam Holes Drilled:

No

Oiling Style:

Through pushrod

Machined for O-Ring:

No

Heat Crossover:

No

Quantity:

Sold as a pair.

Notes:

Designed for use with hydraulic flat tappet camshafts less than .550 in. lift. Requires use of hardened pushrods. Part number EDL-9680 head bolt bushing kit required for use with 7/16 in. head bolts. The valve and seat combination, used in these heads, is not recommended for use with a hydraulic or mechanical roller camshafts.

Edelbrock E-Street Cylinder Heads

Are you looking for a set of entry-level street performance heads for your modern street rod, muscle car, or truck? Edelbrock E-Street cylinder heads are just the ticket. These heads feature A356 aluminum castings that are heat-treated to T-6 specs for superior casting strength and quality. Their modern combustion chamber design helps to improve the combustion process and their larger-than-stock intake and exhaust ports help to move more air through your engine. These features improve an engine's efficiency, resulting in more horsepower and torque and improved mileage potential. All Edelbrock E-Street cylinder heads are assembled with manganese bronze valve guides, powder metal interlocking valve seats, and stainless steel one-piece valves with hardened valve tips. Edelbrock E-Street cylinder heads are ideal for entry level street performance engines.
